IEC60884-1 Temperature Rising Tester - Plug Socket Tester , 0-1000A Test Current

  • 1
  • 2
  • 3

Brand Name : HongCe

Model Number : HC9910B

Certification : Third part calibration certificate(cost additional)

Place of Origin : Chnia

MOQ : 1 Set

Price : Negotiatable

Payment Terms : T/T

Supply Ability : 20 set per month

Delivery Time : 30 days

Packaging Details : Plywood

Test station : 6 stations

Test current : 0-1000A adjustable

Test voltage : 5V, 12V, 24V, 48V

Temperature : 0-150°C

Test object : Circuit board

Standard : IEC60884-1, VDE0620, UL

Product Name : Temperature Rising Tester

Warranty : 1 Year

Contact Now

IEC60884-1 Temperature Rising Tester - Plug Socket Tester, 0-1000A Test Current



Product Introduction:

This device is in accordance with IEC60884-1 Fig 44 Clause 19 of the temperature rise to design and manufacture, it is mainly used to test the plug device and its accessories around, such as dimmers, fuses, switches, power regulators, etc., and it cannot reach excessive temperatures during normal use. This device adopts a high-precision digital meter, sensor signal input with 6 work stations, over-temperature and overload protection with voice prompts, strong applicability and stable performance                  Plug Socket Tester

Standard: IEC 60884-1 2013 clause 19, IEC 60998.1, VDE0620

Application: This device is use for test the temperature rise under normal operation of electrical appliances.

Test sample: Household plugs and sockets                            Plug Socket Tester

Feature: External type, thermocouple wire directly connected to the sample

Parameters:

Item HC9910B
Working station 6
Testing current 50-1000A is adjustable
Testing voltage 5V,12V,24V,48V
Timer 0-9999s is adjustable, digital display
Temperature measuring meter 0-150℃ digital display
Power supply 220V,50HZ
standard UL
Test object circuit board



Sizes of the wire (single copper core) Max. Load Current
1.5mm² 20A
2.5mm² 28A
4mm² 38A
6mm² 48A
10mm² 65A
16mm² 88A
25mm² 113A
50mm² 142A
70mm² 171A
95mm² 218A
120mm² 265A
150mm² 305A
185mm² 355A
240mm² 410A
300mm² 490A
400mm² 560A
500mm² 650A
630mm² 750A
2.5mm² 880A
800mm² 1100A
