Pendulum rod 0~90° High Energy Pendulum Impact Testing Machine for Impact Testing Machine
Product Introduction with Impact Testing Machine:
The test apparatus is designed and manufactured according to the requirements of IEC61439-1:2009,IEC62262:2002 clause 6 and IEC60068-2-75, it applies to test the mechanical collision strength degree when the electrical equipment shells collide external objects.
The frame of this device is welded by stainless steel, the structure is compact and durable. The mounting brackets can be adjusted up and down, and the impact angle is 0-90 ° adjustable, the whole test apparatus is easy to be operated.
Product Parameters with Impact Testing Machine:
1. Pendulum rod angle: 0-90 ° adjustable, scale display
2. Pendulum rod length: 1000mm,φ9 is used for 2J , φ15.9 is used for 5J,10J, 20J and 50J
3. Equipped with 2J,5J,10J,20J,50J striking elements
4. Impact height: 200mm~1200mm adjustable
Impact energy, equivalent mass and drop height chart:
| Energy/J | 2 | 5 | 10 | 20 | 50 |
| Equivalent mass kg(±2%) | 0.5 | 1.7 | 5 | 5 | 10 |
| Height of fall mm±1% | 400 | 300 | 200 | 400 | 500 |
Mechanical Principles with Impact Testing Machine:
This apparatus is designed and manufactured according to IEC 60068-2-75, the front end of the pendulum rod is connected to striking elements, adjust the pendulum rod to a certain height and release it, then the pendulum rod swing freely to impact the test sample surface within a define area. Different equivalent mass striking elements are corresponding to different impact energies, and applies to different electrical equipment enclosure strength test.
Product Image with Impact Testing Machine:
