Connector Pull And Twisting Force Test Machine
Product Standard with Tensile Strength Testing Machine:
IEC 60320-1 clause 23.7 Appliances couplers for household and similar general purposes-Part 1:General requirements.
Product Application Range with Tensile Strength Testing Machine:
Suitable for the connector testing of rated voltage not exceeding 250V, the rated current is not more than 16AD of the AC two pole appliances couplers.
Test sample:Connectors.
Product Features with Tensile Strength Testing Machine:
The tester is controlled by PLC intelligent electrical equipment and has a touch screen operation interface.
The equipment is equipped with an independent motor drive mechanism to control tension, torsion and bending force respectively, so as to ensure that the tests do not interfere with each other and guarantee the accuracy of the tests.
The motor-driven ball screw mode is adopted for the three kinds of force tests. The lifting movement is realized by the tray driving the weight, which truly simulates the process of applying and releasing force through lifting and lowering, and the force application time is controllable.
Product Parameters with Tensile Strength Testing Machine:
| Control System | MITSUBISHI PLC control, 7-inch color touch screen operation |
| Drive Mode | Motor + precision screw and guide rail forming transmission mechanism |
| Working Station | Single station, three types of force tests operate independently |
| Pull/Twist/Bending Time | 0-999.9s, adjustable preset |
| Pull/Twist/Bending Speed | 0-100mm/s, adjustable preset |
| Pull/Twist/Bending Displacement | 0-80mm, adjustable preset |
| Load Weight | Pull force: 100N; Twist force: 40N; Bending force: 40N |
| Twist Arm | 50mm |
Product Image with Tensile Strength Testing Machine:
Our advantage service:
We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.
Technical support:
All our workers are experienced and skilled.
After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.
About Us:
Guangzhou Hongce Equipment Co., Ltd is a leading company in inspection equipment industry, established in 2003 and located in Guangdong, China. Our company introduced advanced equipment, combined with the most advanced technology production processes, strict quality control system to control the entire process of production. The company combined with a number of high-tech management personnel and advanced equipment, and together with the modern management, computer design and control, our products has reached the international advanced level. The company set R&D design, production, sales as one, specializing in producing electric wire inspection equipment of plug and socket, mechanical robustness testing equipment of electronics, inspection equipment of electronics’ on-fire danger, testing indicator of anti-electric shock and solid objects' entry, general inspection equipment, and other non-standard testing equipment. Our products enhance good selling at home and abroad, and have established supply relationships with a number of well-known companies.
